| Device name: | Android navigation box | Car model: | Lexus RX 12-16 model |
|---|---|---|---|
| Hardware: | 1.6GHz quad core 2GB RAM | Flash: | 16GB |
| Wireless: | bluetooth wifi | Control: | Touch screen Lexus origin knob mouse and touchpad |
| Android: | 6.0 | Navi: | iGO Google map waze etc |
Features:
1. Using GPS global satellite positioning technology;
2. Built-in GSM phone module, supports text messaging,calling and Internet network communication;
3. Equipped with high-definition digital camera, can capture vehicle image at real-time ;
4. Remote monitoring vehicle fuel (oil, oil spills, oil steals, fuel consumption, etc.);
5. Remote off oil, power, designing cross-border, speeding and emergency alarm functions;
6. Special Vehicle Monitoring (dump trucks pouring, mixers rotating, etc.);
7. Support GOOGLE maps, 3D Virtual Monitor;
8. LED advertising screens can be expanded, update the display content remote real-time;
Software: We will install the software on your own server for free if your quantity is add up to 200pcs.
Spec:
1.Image transmit
2.Real-time locating
3.SOS button/Power-cut Alarm
4.Listen by telephone
5.E-fence/Over-speed Alarm
6.Control engine remotely
7.Check fuel
8.LED Advertising screen
|
Size |
137*78*29mm |
|
Working Voltage |
DC:6.3~40V |
|
Input Fuse |
5A |
|
Working Temperature |
-40~85°C |
|
Humidity |
10% to 90% |
|
CPU |
TI:MSP430F5419(100MHz) |
|
GSM Module: |
Tri-mode:850/900/1800/1900MHz Tally with: GSM phase 2/2+ -Class 4 (2W @ 850/900MHz) -Class 1 (1W @ 1800/1900MHz) Max RF Output: 33.0dBm±2dBm Dynamic Input Range: -15 ~ -102dBm Receiving delicacy: Class RBER≤2%(-102dBm) Frequency Stability: > 2.5ppm Max Frequency Deviation: ±0.1ppm RMS Deviation: ≤5deg |
|
GPS Module
|
GPS chip set: SiRF Star IV Frequency: L1, 1575.42 MHz Number of Channel: 20 Reacquisition: 0.1 sec, average Hot boot: 2 sec., average Warm boot: 38 sec., average Cold boot: 44 sec., average Altitude limit: 18000 m Velocity limit: 515 m/s |
|
Input I/O |
7 I/O input Port 1 port use to check the engine ( ACC check) 1 port use to SOS 1 A/D Input port( Fuel check) 1 Output port ( Car engine control ) 3 Extend ports ( Input/Output control by software) |
|
RS232 |
Two One is connect to the camera (130M pixel) Other is extend ports, ,can connect to LED screen. |
|
Microphone |
3.5mm single track |
|
earphone |
3.5mm |
|
Current |
Not working Current 16mA working Current:60~150mA Current of opening infrared of Camera at night :100~200mA Charging current: Max<500mA |
|
Battery |
Lithium battery :400mA( working time is about 3.5 hours) |
|
Accessories |
device, Connecting cable ,GPS antenna ,GSM antenna, Engine controller, SOS button, Microphone, Camera, LED advertising display(optional) |
